يمتلك قسم الفيزياء عدة أجهزة بحثية تستخدم في تصنيع وتحليل العينات، أهمها :





Atomic Force Microscope AFM

The Agilent 5500 AFM/SPM microscope offers numerous unique features, such as patented top-down scanning and unrivalled environmental and temperature control, while providing maximum flexibility and modularity. The universal microscope base permits easy integration with an environmental chamber or an inverted optical microscope. Sample preparation is made easy with our unique sample plates designed for your application including imaging in fluids. A top-down optical axis through the scanner allows an unobstructed view of the cantilever and the sample without sacrificing sample handling. The scanner’s modular nose cone makes changing imaging modes quick and easy. The Agilent 5500 SPM/AFM is a high performance system that facilitates advanced applications solutions. It offers atomic resolution and is ideal for electrochemistry, polymers, and soft material applications



NanoFiber Electrospinning Unit

The Nanofiber Electrospinning Unit (NEU) can produce nanofibers from 50nm to 800nm in diameter. The biggest feature of the NEU is its ability to use electrospinning to easily produce nanofibers using small amounts of polymer.
Currently, the use of nanofibers in the IT, Biotech, Healthcare and Fabrics industries is expected to increase dramatically, taking advantage of the increased surface area and fineness of materials and textiles made from nanofibers



Dynamic Mechanical Analyzer

Dynamic Mechanical Analyzer (TA Instruments Q800) is the world’s best selling DMA, for very good reasons. It utilizes state-of-the-art, non-contact, linear drive technology to provide precise control stress, and air bearing for low friction support. Strain is measured using optical encoder technology that provides unmatched sensitivity and resolution. With its unique design, the Q800 easily outperforms competitive instruments, and is ideal for high-stiffness applications including composites



Precision Impedance Analyzers

The 4294A precision impedance analyzer is an integrated solution for efficient impedance measurement and analysis of components and circuits. The 4294A covers a broader test-frequency range (40 Hz to 110 MHz) with Basic impedance accuracy:+/-0.08 %. Excellent High Q/Low D accuracy enables analysis of low-loss components. The wide signal-level ranges enable device evaluation under actual operating conditions. The test signal level range is 5m V to 1 Vrms or 200 uA to 20m Arms, and the DC bias range is 0 V to +/-40 V or 0m A to +/-100m A. Advanced calibration and error compensation functions eliminate measurement error factors when performing measurements on in-fixture devices. The 4294A is a powerful tool for design, qualification and quality control, and production testing of electronic components. Circuit designers and developers can also benefit from the performance/functionality offered



UV-VIS-NIR Spectrophotometer

The UV-3600 UV-VIS-NIR Spectrophotometer is a new additional model in our product lineup of high-end UV-VIS-NIR spectrophotometers
The UV-3600, a successor model to the UV-3150/3101, is a unique UV-VIS-NIR instrument that provides for optimum sensitivity from 185-3,300nm



Sputter Coater

The K575XD is a compact, dual head turbomolecular-pumped sputter coater optimised to deposit fine metal coatings for SEM, FEG-SEM and thin film applications. The K575XD has two independent sputtering heads, which allows sequential sputtering of two metals without the need to break vacuum
The sputter coating process is completely automatic, making the K575XD ideal for inexperienced or occasional users. The K575XD is fitted as standard with chromium(Cr) and gold (Au) targets, but a wide range of oxidising and non-oxidising metals are available



Automated Spin Coater

SCS P-6708 and P-6712 (12-inch bowl) desk top precision spin coating system are designed for laboratory use and low volume production coating applications. They are designed to accurately apply a variety of liquid materials to plannar substrates.

​​​Electrochemical impedance spectroscopy2.jpg

Research Equipments:
Dielectric and Electrochemical Impedance Spectrometer

Model/Make :
 Novo Control Technologies

Contact Person:
 Dr. Mahmoud


Gas-sensor characterization2.jpg

Research Equipments:
Gas sensor characterization system with Linkam microscopic hot/freeze stage

Model/Make :
 GSM-600A, Phocos, 2010-DMM, 6487 pico-ammeter, Keithley

Contact Person​: Dr. Abdullah Aljaafari and Dr. Javed
Laser microscope2.jpg

Research Equipments:
Laser Diffraction Particle Size and Charge  Analyzer

Model/Make :
 Microtrac-Zetatrac

Contact Person​: Dr. Osama
Layer controlled chemical vapor deposition2.jpg

Research Equipments:
Chemical Vapor Deposition for (MoS2) Atomic Monolayers

Model/Make :
 Sulfur Science (CVD smart systems)

Contact Person​:​ Dr. Abdullah Aljaafari and Dr. Javed
Physical property measurement system2.jpg

Research Equipments:



Model/Make :




Contact Person​:

Research Equipments:
Plasma Enhanced Chemical Vapor Deposition (PECVD) Recipes for carbon NanoTubes, and ZnO NanoWires

Model/Make : First Nano (CVD corporation


Contact Person​Dr. Abdullah Aljaafari and Dr. Javed​

Research Equipments:

Thermal Gravimetry Analyzer (TGA)

Model/Make :
 Q50-TA Instruments (Thermal Analysis )




Contact Person​: Dr. Abdullah Alnaim

Research Equipments:
X ray Photoelectron Spectrometer (XPS)

Model/Make :
 Omicron

Contact Person​Dr. Javed

Research Equipments:
μ - Raman Spectrometer with He-cryostat

Model/Make :
 Horiba LabramHR

Contact Person​: Dr. Javed​
​​

:
